1. Prepare Components: Lay out all parts. Separate the “L” (left) and “R” (right) mounting brackets and mirror brackets.

2. Install “L” Mounting Bracket (Left arm)

• Position the bracket near the front of the cab on the left skid steer arm.
• Loop strap under and back up the inside of the arm, avoiding hydraulic lines and other obstacles.
• Adjust the outer strap cover over any sharp edges/corners.
• Thread strap through the ratchet and tighten firmly.

3. Attach Mirror to “L” Mirror Bracket

• Remove the outermost nuts/washers from the mirror’s top and bottom.
• Insert mirror into “L” mirror bracket hole/slot.
• Reattach nuts/washers and hand-tighten.

4. Connect “L” Mirror Bracket to “L” Mounting Bracket

• Remove nuts/washers from the two bolts on the mounting bracket.
• Bring the mirror bracket over the mounting bracket, sliding the top bolt into the main shaft hole and the bottom bolt into the adjustment slot.
• Reattach nuts/washers and hand-tighten.

5. Adjust and Secure

• Set mirror tilt and angle for optimal rear and blind spot view.
• Tighten all nuts securely (top/bottom of mirror, and mounting bracket) with a ½” wrench.
• Check for slack; tighten ratchet if needed.

6. Repeat for “R” Side

• Follow steps 2–5 for the right arm.
